Tanker DWG Block for AutoCAD

Tanker DWG Block for AutoCAD

cisterna – plant – cuts.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Castle of armed with var est cms, Champs de cms, pending, Var cms both directions double overlapping layer, Wall of tabicon seated with, Carcamo de cms, Cistern detail, Cistern detail, Chain enclosure with var est cms, Slab reinforced concrete var double layer overlap, Padding with improved grass cms material, Concrete foundation foundation double layer overlap, Polished polished finish reinforced with integral impermeant, Castle of armed with var est cms, Filling with improved material compacted in layers of cms cms approx., Register of cms sheet cover lime. Reinforced with

Raw text data extracted from CAD file:

2.10 3.10 2.40 3.50 0.10 0.10 1.50 0.30 0.15 0.10 0.10 0.30 0.30 0.30 CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CHAFLAN DE CEMENTO-ARENA 1:5 DE 10x10 CMS PENDIENTE 2% 5 5 VAR #3 @30 CMS AMBOS SENTIDOS DOBLE CAPA TRASLAPADA MURO DE TABICON 12x9x27 ASENTADO CON CEMENTO-ARENA 1:5 X X' CARCAMO DE 30x30 CMS DETALLE DE CISTERNA (PLANTA) 5 5 5 5 5 5 5 0.10 0.10 5 5 5 DETALLE DE CISTERNA (CORTE X-X') CADENA CERRAMIENTO DE 30x15 ARMADO CON 6 VAR #3 Y EST #2 @ 12 CMS LOSA TAPA CONCRETO F´C=200 kg/CM2 ARMADO VAR #3@20cms DOBLE CAPA TRASLAPADA RELLENO CON MATERIAL MEJORADO Y 15 CMS DE LAMA PARA PASTO LOSA CIMENTACION CONCRETO F´C=200 kg/CM2 ARMADO VAR #3@20cms DOBLE CAPA TRASLAPADA APLANADO ACABADO PULIDO REFORZADO CON IMPERMEALIZANTE INTEGRAL CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS CASTILLO DE 20x15 ARMADO CON 4 VAR #3 Y EST #2 @ 12 CMS RELLENO CON MATERIAL MEJORADO Y COMPACTADO EN CAPAS DE 20 CMS 50 CMS APROX. REGISTRO DE 60x60 CMS Y TAPA DE LAMINA CAL. REFORZADA CON

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, block, cisterna, cuts, DWG, einrichtungen, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, plant, provision, tanker, wasser bestimmung, water
